Turns ratio and phase tester (SS310)
Product 1/1  Transformer turns ratio and phase tester
  • Turns ratio and phase tester (SS310)
  • Turns ratio and phase tester (SS310)
  • Turns ratio and phase tester (SS310)

    Description:
    This (SS310) turn ratio meter is a reliable test instrument used for product inspection and sample analysis in the manufacturers of transformer, radio and TV set or relative scientific research units. 100 internal instrument setup can free you from the trouble of repeated parameter setup as well as save much time. As an optimum tool, it can improve product quality and increase production efficiency as well.
    Key Features:
    Test Frequency: 1KHz, 15.75KHz, 20KHz, 50KHz
    Basic Measurement Accuracy: ± 0.5%
    100Groups internal instrument Seting Store / recall Capability
    GOOD  /NG Judgment
    Order project:
    SS310
    310 Cross-clip Cable
    310 Big or big-pin Fixture (optional, Custom-made available)
    310 Test Box
    310 Test Box Jump wires Board

    Specification:

    Model SS310
    Test parameter (Np, Ns) (Vp, Vs) ;  (Np, Ns) (Ns, Np)
    Measure signal
    Meas. Level 0.1V~10V±10%, 0.1V/step programable
    Meas. Frequency 1KHZ , 15.75KHZ , 20KHZ , 50KHZ
    Base accuracy ±0.5%
    Meas. Range 0.01~9999.9T
    Meas. Speed
    Fast 5Meas./S
    Slow 2.5Meas./S
    Trigger automatic, manual
    Display 4.5pcs digitals×2
    Memory 100Groups seting
    Automatic judgement pass or fail
    Common spec.
    Environment temperature :10 ºC ~ 40 ºC ,humidity :10%~90%RH
    Power consuming Max.100W
    Power 90~125V or 190~250V,48HZ~62HZ
    Weight 8Kg
    Meas. (W×H×L ) 405×130× 365mm
